Air Filter Bubble Point Testing Filter Integrity Testing Equipment for Sale
BNT-V4.0 automatic filter integrity tester is the filter material and filter system integrity test of special equipment, it can be bubble point and diffusion flow (forward flow) method, water intrusion test method to detect filtering accuracy and completeness of filter and filtration systems. Test methods meet FDA, National Pharmacopoeia and the GMP standards for sterile filter validation requirements.
Application Range:
Disc Membrane:Φ25mm-Φ300mm;
Standard Cartridge:2.5″- 40″
Capsule & Mini Catridge
Air filter test :2.5″- 40″
Features:
- 5.7 "digital LCD display with backlight, clear display;
- Pure Chinese operating environment, in line with people's habits;
- Real-time display of test data and curves, monitor the entire process of testing;
- Dual-core computing, it covers all the features of similar foreign instrument.
- With a better user management features, users may be required to change the password needed.
- An increase of the test filter automatic protection against over-voltage test because of damage caused to the filter.
- A setting item automatically print function, allowing users to operate more simple and convenient.
- The hydrophobic filter designed specifically for the "Water immersion" test, solve the hydrophobic filter can only be used to test the integrity of the organic solvent infiltration shortcomings, to fill a gap.
- With a more sophisticated vitality, better algorithms, the instrument can achieve the detection of flat membrane filter diffusion flow, which is important to determine the integrity and properties of the film.
Technical Parameters:
| Power requirements | 170-240V AC, 50/60Hz；110W |
| Maximum operating pressure | 9999 mbar |
| Minimum intake air pressure | 3000 mbar |
| Overall dimensions | 240(W) x 380(D) x 280(H) |
| Test Range | maximum test pressure: 500-6900mbar |
| Test Accuracy | Net volume test: ± 4%; bubble point: ± 50mbar; diffusion flow: ± 4%; water immersion: ± 0.1ml / min |
| Operating conditions | Ambient temperature: + 5 ℃ ~ + 35 ℃; Relative humidity: 10-80% |
| Test Processed | Net volume test: 5 min ± 2min; diffusion flow test: 8 min ± 2min; Simple bubble point test: 10 min ± 2min; enhanced bubble point test: 20 min ± 2min; Water immersion test: the setting of test time + 5min ± 2min; |
| Printing function | Wide line printing, output test parameters, test results, automatic print function |
| Test recording function | 500 groups of test results (including test curve), can be increased to 1000 set of test results according to user needs |
| Display screen | 5.7" TFT；monochrome |
| Serial port connection mode | RS232； |
| Language | English |
FAQ 1. Are you a factory or trading company?
We are a factory.
FAQ 2. Can you supply OEM?
OEM is available.
FAQ 3. What's the MOQ ?
(1). MOQ is 1 piece. The disposable supplies order usually at least 1 box.
FAQ 4. How about the order processing and lead time?
After order confirmation and receive the advance payment, we will prepare the machines and goods. Usually could ready within 10 working day, when dispatch, will inform client and send the documents for client making import customs clearance.
FAQ 5. What quality will be ensured?
100% new and quality inspection before delivery from factory.
Stable export box for good package.
FAQ 6. Can you guide the working?
The machine will deliver with English display, English manual and video for installation and operation.
FAQ 7. How can your engineer replace parts if they are not beside the machine?
Bonnin’s engineer could provide the solutions by email and video. In warranty period, we can send spare parts for free and life-time technical support for spare supply.
